Model No.
AF-AC-07-B-A-O-1-SE
Rated Power
7 kW
Installation Method
Wall-mounted
Feeding Method
Bottom in, bottom out
Equipment Dimensions
180 × 130 × 120 mm (plastic enclosure)
Equipment Weight
3 kg
Input Voltage
AC 220 V ±20%
Input Frequency
50 Hz ±10%
Output Voltage
Rated Input / Output Current
32 A
Current Limit Protection
≥ 110%
Metering Accuracy
Class 1.0
Charging Method
Plug and charge
Safety Functions
Overvoltage protection, undervoltage protection, overload protection, grounding protection, overcurrent protection, leakage protection, overtemperature protection
Working Temperature
-30 °C to +50 °C
Working Humidity
5%–95% non-condensing
Working Altitude
≤ 2000 m
Ingress Protection
IP54
Cooling Method
Natural air cooling
Noise Level
≤ 40 dB
MTBF
30,000 hours
